650nm 5mw laser diode TO-18 hair removal DVD burner
650nm 5mw laser diode TO-18 hair removal DVD burner
650nm 5mw laser diode TO-18 hair removal DVD burner
650nm 5mw laser diode TO-18 hair removal DVD burner
650nm 5mw laser diode TO-18 hair removal DVD burner

650nm 5mw laser diode TO-18 hair removal DVD burner

Model NO.
BOB650T5-TO18
Price:
USD 1.00-5.00 / pieces
Delivery:
FOB
Minimum order quantity:
10 pieces
Supply Ability:
15000 pieces / Week
Country of Origin:
Guangzhou
Quantity:
  • Place of Origin:CN;GUA
  • Brand Name:BOB
  • Max. Reverse Current:standard
  • Max. Forward Voltage:2.2V
  • Package Type:Through Hole
  • Type:Laser Diode
  • Max. Forward Current:0.5A
  • Max. Reverse Voltage:standard
  • Model Number:BOB650T5-TO18
  • package:TO-18
  • power:5mw
  • wavelength:650nm
  • color:red beam
  • Storage Temperature:-45 to 85 degree
  • Work temperature:-10 to 55 degree





                                                     650nm 5mw laser diode TO-18






Application:



Indicator
Pointer
Barcode Scanner
Laser Hair growth apparatus
Laser medical equipment


BOB650T5 650nm 5mw laser diode TO-18

Parameter

Symbol

Min

Typ

Max.

Unit

Threshold current

  Ith



  25

 35

  mA

Operating current

  Iop



 80

 95

  mA

Operating voltage

  Vop



 2.5

 3.0

 V

Slope efficiency

  η

 0.6

 0.8

 1.0

  mW/mA

Beam divergence(FWHM)- Parallel

  θ

 8

 10

 12

  deg

Beam divergence(FWHM)- Perpendicular

  θ⊥

 15

 19

 22

  deg

Emission point accuracy

  xyz

 -80



 80

  um

Lasing wavelength

  λp

 650

 655

 660

  nm

Operating Temperature

  TStg

 -40

 25

 85

  °C





Shipping


1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;


2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;


3. Customers specifying freight forwarders or negotiable shipping methods!


4. Delivery Time: 2-3 days for samples; 5-7 days for batch goods.







Payment Terms



1. T/T (Wire Transfer)



2. WESTERN UNION



Delivery Date







Company Overview



if you want konw more.  You can leave a message to me.

this our company's website http://boblaserdiode.en.alibaba.com/

 12345



Our  Product :



We company mainly produces the following product package of the semiconductor laser: 405nm, 445nm, 635nm, 638nm, 650nm,780nm, 808nm, 830nm, 850nm, 915nm, 940nm, 980nm, 1064nm, 1310nm, 1550nm,various   power specifications (1mW to 10W),TO -5 TO-3,C-Mount as well as CT-Mount,  the F-Mount   and  a  variety  of  purposes (communication, pumps, medical and beauty, display, printing, etc.) .semiconductor lasers.


We company has passed ISO9001, European CEcertified,RoHS certification of the European environmental protection,the U.S. FDA, Japan JQA. BOB brand in the international community gained a high reputation in the market.
