Model NO.
BOB-VFL650-1S
Delivery:
FOB
Supply Ability:
10000 piece / Month
Country of Origin:
For Guangdong
Quantity:
  • Place of Origin:CN;GUA
  • Brand Name:BOB
  • Model Number:BOB-VFL650-1S
  • patents:Design Appearance patents
  • Price:Factory price
  • Color:silver
  • Materia:High-end imports of aluminum
  • Wavelengths:650±10nm
  • Output Power:5mw,10mw,20mw,30mw,40mw,50mw
  • Optical Connector Type:2.5mm,1.25mm
  • Operating Model:CW,Pulse
  • Power Supply:2x"AA"
  • bettery life:up to 60 hours
Product Description


20mw / 30mw / 50mw Visual Fault Locator Fiber Checker (range 50km)

BOB-VFL650-1S
Brand NameBOB
Colorsilver
MateriaHigh-end imports of aluminum
Wavelengths650±10nm
Optical Connector Type2.5mm,1.25mm
Operating ModelCW,Pulse
Power Supply2x"AA"
Output Power 5mw10mw20mw 30mw50mw
Laser range(>5km)(>10km)(>20km)(>30km)(>50km)
battery lifeLong battery life (up to 60 hours) .Low battery warning
Optical connector2.5mm universal connector,for 1.25mm connectors, FC(male)-LC(Female) adaptor also can be provided on request
Operating modeOperates either in CW or Pulsed mode with constant output power
FeatureDrop-resistant and dust-proof design of laser head
Laser case ground design prevents ESD damage
Portable and rugged
360° rotation protecting ring
Easy to use
ApplicationMaintenance in telecom, CATV
Test Lab of optical fibers
Fiber routing and continuity checking in optical networks
Other fiber optic measurements
FuntionFind breakpoints, poor connections, bending or cracking in fiber optic cables
Find faults in an OTDR dead zone
Is used for end-to-end visual fiber identification.
